NESHAP Requirements vs. PPC Performance

NESHAP
New Installation

PPM-319 XL System
PPM-319 XL System

Liquid Phase Liquid Phase
Efficiency Particle Size Efficiency Particle Size
>95% >2.0 micron 97.0% >1.88 micron
>80% >1.0 micron 91.4% >0.94 micron
65% .42 micron 78.5% >0.37 micron

Solid Phase

Solid Phase
95% 2.5 micron 98.6% >2.14 micron
85% 1.1 micron 92.0% >0.87 micron
75% .70 micron 86.8% >0.59 micron


Information based on independent testing by LMS Technologies using Test Method 319.


Spray Removal Efficiency & Paint Holding Capacity

Initial Pressure Drop of the 2 Filter System 0.19" water
Final Pressure Drop of Loaded Filter System 0.69" water (After 1st filter loaded)
Paint Holding Capacity of 1st Filter 1156 grams 2.5 lbs.
Initial Removal Efficiency 99.99% (After 1st filter loaded)
Average Removal Efficiency 99.99% (Both filters loaded)


Conditions Pertinent to Filter Change

Filter Pressure Drop Weight Gain
Paint Pockets Pad 0.69" water 1198 g. = (2.64) lbs.
PPM-319 XL Bag 1.13" water 1599 g. = (3.53) lbs.





Converting from Pads to Rolls Pays HUGE Dividends!

Click here to found out how converting your booth from pads to rolls can save your company money, and how Paint Pockets® makes the process easy.
